Razdelilnik ERP12-5 001101298

Specifikacija

Koda izdelka:
001101298
Opis:
ERP12-5
Ime razreda:
Razdelilnik
Stopnja zašcite:
II
Način montaže:
Podometni razdelilnik
Nazivni tok (A):
63
Nazivna napetost (V):
400
IP zaščita:
IP40
Št. modulov (skupno/na vrstico):
60 / 12
Velikost ohišja (št. vrstic):
5
Vrata (material, barva):
Metal, white
Podstavek (material, barva):
Plastična, bela
Število PE/N sponk (povezave):
24 / 66
Test z žarečo žico (°C):
650

Dokumenti

Produkt

Teža izdelka
5.75  kg
Carinska tarifa
85369001

Transportno pakiranje

Količina
1
EAN
3838895804475
Teža
6.1  kg
Odpremna količina
40

Slike in diagrami

Programska oprema

Software is provided as is without any guarantees or warranty. The author is under no obligation to provide support, service, corrections, or upgrades to the free software programs or drivers.
001101298 Flush mounted enclosure Distribution box, ERP12-5 ETIBOX Distribution boards DIDO DIDO ERP Flush mounted Metal door Metal door Enclosures, distribution boards, equipment ETIBOX Distribution boards and enclosures DIDO Flush-mounted plastic boards IP40 with metal door ERP12-5 Rated current 63A Rated voltage 400V Rows 5 Mounting type Flush mounted Type of door Metal Height 809mm Width 288mm Depth 120mm IP rating IP 40 Color White Catalogue Group DIDO ERP Protection Class II Number of modules 60 Total/per row 12Total/per row Frame size 5Number of rows Door Metal, whitematerial, color Enclosure base Plastic, whitematerial, color Number of PE/N terminals 24 connections 6x11connections Glow wire test 650°C Distribution box ERP12 Flush mounted IP 40 60 / 12Total/per row Metal, whitematerial, color Distribution box ERP12 Flush mounted IP 40 60 / 12Total/per row Metal, whitematerial, color
