Talilni vložek NHS2/394/M aR 100A/4000V DC 004735601
Specifikacija
- Koda izdelka:
- 004735601
- Opis:
- NHS2/394/M aR 100A/4000V DC
- Ime razreda:
- Talilni vložek
- efuse:
- 1
- Velikost:
- NH2
- Tip:
- NH-S
- Nazivni tok (A):
- 100
- Nazivna enosmerna napetost (V):
- 4000
- Karakteristika:
- aR
- L/R (ms):
- 15
- DC Izklopna zmogljivost (kA):
- 30
- Aplikacije:
- Fuse link for DC link protection of railway inver
- Dimenzija:
- S394mm
- Indikator:
- Centre trip indicator for MK
- Izgubna moč (W):
- 58
- Skupni Joulov integral (A2s):
- 20.000
- Talilni Joulov integral (A2s):
- 2.300
- Standardi:
- IEC 60269-4 , IEC 60077-5
Dokumenti
Logistični podatki
Produkt
- Carinska tarifa
- 85351000
- logis_net_width
- 66 mm
- logis_net_height
- 419 mm
- logis_net_depth
- 73 mm
Transportno pakiranje
- Količina
- 1
- EAN
- 3838895689737
- Teža
- 3.99 kg
- Odpremna količina
- 140
ETIM klasifikacija
- Klasifikacija
- EC000055
- Ime razreda
- Low Voltage HRC fuse
- Construction size
- Other
- Rated current
- 100
- Rated voltage
- 4000
- Voltage type
- DC
- Rated switching capacity
- 30
- Utilization category
- aR (accompanied semiconductor protection)
- Type of fuse status indicator
- Centre fuse status indicator
- Insulated metal gripping lugs (IMGL)
- Ne
