VVC3 7,2kV/63A 004220015

Specifikacija

Koda izdelka:
004220015
Opis:
VVC3 7,2kV/63A
Nazivni minimalni odklopni tok (A):
220
Hladna upornost (mΩ):
7.5
Nazivni tok (A):
63
Tip:
Nova VVC 50N z udarno iglo
Velikost:
192
Karakteristika:
Other
Nazivna AC napetost (V):
7200
Indikator:
50N udarna igla
AC Izklopna zmogljivost (kA):
63
Izgubna moč (W):
42.5
Aplikacije:
Zaščita transformatorja, zaščita motorja, zaščita kondenzatorske baterije, vgradnja v obročno glavno enoto

Dokumenti

Produkt

EAN koda izdelka
3838895914464
Teža izdelka
1.6 kg
Carinska tarifa
85351000

Osnovno pakiranje

Osnovno pakiranje
1
EAN koda osnovnega pakiranja
3838895914464
Teža osnovnega pakiranja
1.6 kg
Volumen osnovnega pakiranja
5.14

Transportno pakiranje

Pakirna količina
3
EAN koda odpremnega pakiranja
3838895914471
Teža odpremnega pakiranja
5.42 kg
Volumen pakirne embalaže
15.42
Odpremna količina
126
Volumen paletnega pakiranja
647.64

Slike in diagrami

Programska oprema

Konfigurator Software is provided as is without any guarantees or warranty. The author is under no obligation to provide support, service, corrections, or upgrades to the free software programs or drivers.
004220015Fuse link, VVC3 7,2kV/63AVVHigh voltage fuse-links7,2 kV192 mm192 mmVVCFuse links for medium voltageVVCVVC3 7,2KV/63ARated current 63AType NEW VVC 50N strikerSize 192Characteristics OtherRated AC voltage 7200VIndicator 50N striker forceBreaking capacity AC 63kAPower dissipation 42.5WApplication transformer protection, motor protection, capacitor bank protection, installation in ring main unitRated minimum breaking current 220ACold resistance 7.5mΩFuse link VVC3 NEW VVC 50N striker 192 63A 7200VFuse link VVC3 NEW VVC 50N striker 192 63A 7200V
