Talilni vložek VVA3 7,2kV/40A 004221113
Specifikacija
- Koda izdelka:
- 004221113
- Opis:
- VVA3 7,2kV/40A
- Ime razreda:
- Talilni vložek
- efuse:
- 1
- Nazivni minimalni odklopni tok (A):
- 140A
- Hladna upornost (mΩ):
- 13mΩ
- Nazivni tok (A):
- 40A
- Tip:
- Nova VVA brez udarne igle
- Velikost:
- 192
- Nazivna AC napetost (V):
- 7200V
- Indikator:
- Brez
- AC Izklopna zmogljivost (kA):
- 63kA
- Izgubna moč (W):
- 285W
Dokumenti
Logistični podatki
Produkt
- EAN koda izdelka
- 3838895911777
- Teža izdelka
- 1.2 kg
- Carinska tarifa
- 85351000
- logis_net_width
- 56 mm
- logis_net_height
- 258 mm
- logis_net_depth
- 56 mm
Transportno pakiranje
- Količina
- 3
- EAN
- 3838895911784
- Teža
- 4.22 kg
- Odpremna količina
- 126
ETIM klasifikacija
- Klasifikacija
- EC003507
- Ime razreda
- Medium-/high voltage fuse
- Rated current
- 40A
- Rated voltage
- 7,2kV
- Voltage type
- AC
- Rated frequency
- 45…60Hz
- Breaking capacity
- 63kA
- Utilization category
- Other
- Application
- Other
- Length
- 192mm
- Diameter
- 53mm
- Performance category according to IEC 60282-1
- Back-up
- With striker
- Ne
- Standard
- IEC
- Installation technique
- Air
