NHS1/110 BAT 80A/550V DC 004723272

Specifikacija

Koda izdelka:
004723272
Opis:
NHS1/110 BAT 80A/550V DC
Nazivni tok (A):
80
Tip:
NH
Standardi:
IEC 60269
Velikost:
NH1
Karakteristika:
gBAT
Nazivna enosmerna napetost (V):
550
Dimenzija:
S110mm
Indikator:
Indikator stanja zgornjega talilnega vložka
DC Izklopna zmogljivost (kA):
30
Izgubna moč (W):
12
Izgubna moč (0,7xIn) (W):
5,4
Skupni Joulov integral (A2s):
3.996
L/R (ms):
10
Talilni Joulov integral (A2s):
1.200
Aplikacije:
Zaščita baterij

Dokumenti

Produkt

EAN koda izdelka
3838895759119
Teža izdelka
0.49 kg
Carinska tarifa
85361090

Osnovno pakiranje

Osnovno pakiranje
3
EAN koda osnovnega pakiranja
3838895694168
Teža osnovnega pakiranja
1.36 kg
Volumen osnovnega pakiranja
1.35

Transportno pakiranje

Pakirna količina
24
EAN koda odpremnega pakiranja
3838895694175
Teža odpremnega pakiranja
11.23 kg
Volumen pakirne embalaže
15.39
Odpremna količina
1248
Volumen paletnega pakiranja
800.28

Slike in diagrami

004723272Fuse link, NHS1/110 BAT 80A/550V DCGreen protectNH gBat550V550VNH1S110mmPhotovoltaic, battery fuses and devicesBattery fuse links NHNHS1/110 BAT 80ARated current 80AType NHRated voltage 550VSize NH1Product group Special purpose fusesProduct subgroup BATTCharacteristics gBATRated DC voltage 550VDimensions S110mmIndicator Top fuse status indicatorBreaking capacity DC 30kAPower dissipation 12WCatalogue Group Special purpose fusesCatalogue subgroup Battery FuseStandards IEC 60269Power dissipation (0,7xIn) 5,4WOperating joule integral 3.996A2sL/R 10msPrearcing joule integral 1.200A2sApplication Battery protectionFuse link NHS1/110
